CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

Applied materials:

Mainly used for cutting carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and  many kinds of metal materials cutting and so on.

Applied  Industry:

Applied in sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.

1Machine Name1500W 2200W 3300W High Power Metal Plate Fiber Laser cutting   machine LXF1530G
2ModelLXF1530G
3Laser machine cutting area3000x1500mm(Other size can be customized,such as 4500x1500/6000x1500/6000x2000mm)
4Fiber Laser PowerCO2 Laser Power500w/750w/1000/1500/2200/3300/4000/6000/8000/12000/25000W
5Laser wave length1064nm
6Transmission systemGear   + rails(we   have standard brand,we can also produce as your requirements)
7X.Y axis location accuracy±0.01mm
8X.Y axis repeat location accuracy±0.01mm
9X.Y axis max moving speed30m/min
10Max cutting speed1--30m/min(it will according to metal material and laser power   and machine configuration)
11Cutting thicknessDetailed in the following cutting thickness
12Application MaterialMetal sheetIron/CS/SS/Aluminum/Copper and all kinds metal
13Advantages>Excellent beam quality
  >Simple , compact, electrically and optically efficient
  >Compatibly powerful and reliable
  >Maintenance free
  >multilingual, more than 11 foreign languages
  >3 years warranty .
14Gross weight7500KG
15Net weight7250KG
16Machine sizeExchange table Machine size:5200*3000*2400mmWater chiller +Controller:1830*920*2110mm
17TransportShell frame   for Exchange table Machine 20 Container for Water chiller +Controller

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G


1. Excellent Path Quality: Smaller laser dot and high work efficiency, high quality.

2. High Cutting Speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.

3. Stable Running: adopt top world import fiber lasers, stable performance, key parts can reach 100,000 hours;

4. High Efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.

5. Low Cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.

6. Low Maintenance: fiber line transmission no need reflect lens, save maintenance cost;

7. Easy Operations: fiber line transmission, no adjustment of optical path.

8.Suitable for high power,such as 1500/2200/3300 and high power.

CNC fiber laser 1000w-3000w metal cutting machine for stainless steel metal 4mm in China High speed and good quality  LXF3015G



MaterialThickness(mm)500W1000W1500W2000W3000W4000W6000W8000W10000W12000W
Cutting   Speed(m/min)
Carbon Steel(O2)17.0~8.07.0~9.07.0~11.07.0~12.07.0~12.07.0~12.07.0~12.07.0~12.07.0~12.07.0~12.0
24.0~5.05.0~6.05.0~6.55.0~6.55.0~7.05.0~7.05.0~7.05.0~7.05.0~7.05.0~7.0
32.0~2.52.5~3.02.8~3.83.0~4.63.5~5.03.5~5.03.5~5.03.5~5.03.5~5.03.5~5.0
41.5~2.02.0~2.42.5~3.22.8~4.03.0~4.23.0~4.23.0~4.23.0~4.23.0~4.23.0~4.2
51.2~1.51.5~1.81.8~2.52.2~3.22.5~3.62.5~3.62.5~3.62.5~3.62.5~3.62.5~3.6
61.0~1.41.4~1.61.6~2.22.0~2.82.4~3.02.4~3.02.4~3.02.4~3.02.4~3.02.4~3.0
8
1.0~1.21.1~1.51.4~2.01.8~2.41.8~2.41.8~2.41.8~2.41.8~2.41.8~2.4
10
0.75~0.851.0~1.21.1~1.41.2~1.81.2~1.81.2~1.81.2~1.81.2~1.81.2~1.8
12
0.6~0.70.9~1.00.9~1.21.0~1.51.0~1.51.0~1.51.0~1.51.0~1.51.0~1.5
16


0.6~0.750.7~0.850.7~0.850.7~0.850.7~0.850.7~0.850.7~0.85
20



0.6~0.750.6~0.750.6~0.750.6~0.750.6~0.750.6~0.75
22



0.5~0.650.5~0.650.5~0.650.5~0.650.5~0.650.5~0.65
25



0.4~0.60.4~0.60.4~0.60.4~0.60.4~0.60.4~0.6



MaterialThickness(mm)500W1000W1500W2000W3000W4000W6000W8000W10000W12000W
Cutting   Speed(m/min)
Stainless Steel(N2)110~1215~1810~1535~5045~5545~5545~5545~5545~5545~55
22~4.04.5~6.05.0~7.010~1515~2318~2720~3523~3726~4028~43
30.7~2.02.0~2.43.0~4.05.0~7.07.0~11.010~1515~2019~2423~2827~32
4
1.0~1.52.0~2.83.5~4.54.0~6.05.0~7.510~1414~1718~2222~26
5
0.75~0.851.2~1.71.8~2.52.5~4.04.0~5.08.0~12.011~1414~1716~18
6

0.7~1.00.7~0.82.0~3.23.0~4.06.0~8.08.0~9.59.5~11.010.5~12.0
8

0.5~0.70.5~0.61.2~1.81.5~2.63.5~4.05.0~5.56.5~7.07.5~8.0
10



0.7~0.90.7~1.31.8~2.22.5~3.03.4~3.94.0~4.5
12



0.3~0.40.4~0.61.2~1.51.8~2.12.6~3.13.3~3.6
16




0.3~0.50.8~1.21.5~1.82.2~2.52.7~3.0
20




0.3~0.50.6~0.81.0~1.31.7~2.02.2~2.5
22





0.3~0.40.6~0.751.0~1.21.4~1.6
25






0.3~0.50.4~0.60.6~0.8


MaterialThickness(mm)500W1000W1500W2000W3000W4000W6000W8000W10000W12000W
Cutting   Speed(m/min)
Aluminum (N2)1

10~1530~4530~3835~4045~5545~5545~5545~55
2

5.0~6.010~1512~1613~2220~3027~3533~4036~43
3

2.5~3.55.0~7.06.5~8.07.0~1313~1815~1818~2223~26
4

1.4~2.03.5~5.03.5~5.04.0~5.510~1212~13.515~1819~22
5

0.8~1.02.0~3.02.5~3.53.4~4.05.0~8.09.0~1214~1617~19
6

0.5~0.61.5~2.01.8~3.02.2~3.54.0~6.07.5~9.510~12.513~15
8


0.5~0.60.9~1.30.9~1.62.0~3.04.0~4.85.8~6.56.8~7.2
10



0.4~0.70.55~1.01.0~1.91.5~2.73.0~3.83.7~4.2
12



0.3~0.450.4~0.60.8~1.41.6~1.92.4~2.73.3~3.6
16




0.3~0.40.6~0.91.0~1.21.4~1.61.7~1.8
20





0.4~0.60.8~0.91.0~1.21.2~1.6
22






0.7~0.850.9~1.01.1~1.2
25






0.35~0.450.6~0.70.8~0.9



MaterialThickness(mm)500W1000W1500W2000W3000W4000W6000W8000W10000W12000W
Cutting   Speed(m/min)
Brass (N2)1

8.0~1212~1820~3225~3045~5545~5545~5545~55
2

3.5~5.06.0~8.59.0~1110~1325~3527~3533~4036~43
3

1.5~2.22.5~4.04.0~6.05.0~6.512~1815~1818~2223~26
4

1.0~1.21.5~1.83.0~4.53.0~5.28.0~1012~13.515~1819~22
5

0.6~0.80.8~1.21.5~2.02.0~3.04.5~6.09.0~1214~1617~19
6


0.4~0.51.0~1.61.4~2.03.0~4.07.5~9.510~12.513~15
8



0.5~0.60.7~0.81.6~2.24.0~4.85.8~6.56.8~7.2
10




0.2~0.30.8~1.21.5~2.73.0~3.83.7~4.2
12






1.6~1.92.4~2.73.3~3.6
