Metal Bending Machine Parameter
| Machine tool type | WG67K-200T/6000 | |
| Nomal force | 2000 kN | |
| Bending length | 6000 mm | |
| Distance between columns | 5200 mm | |
| Throat depth | 340 mm | |
| OPen height | 460mm | |
| Slider motion | Stroke | 200mm |
| Fast down speed | 100mm/s | |
| Return speed | 85mm/s | |
| Work pacing | 10mm/s | |
| Slider motion accuracy | Positional accuracy | ±0.03mm |
| Repeated positioning accuracy | ±0.02mm | |
| Main motor power | Power | 11KW |
| Operate system | Model | TP10S System |
| Oil Pump | Model | Silent gear pump |
| Parameters | ||||||
| Model | Weight | Oil Cylinder Diameter | Cylinder Stroke | Wallboard | Slider | Workbench Vertical Plate |
| WG67K-30T1600 | 1.6 tons | 95 | 80 | 18 | 20 | 20 |
| WG67K-40T2200 | 2.1 tons | 110 | 100 | 25 | 30 | 25 |
| WG67K-40T2500 | 2.3 tons | 110 | 100 | 25 | 30 | 25 |
| WG67K-63T2500 | 3.6 tons | 140 | 120 | 30 | 35 | 35 |
| WG67K-63T3200 | 4 tons | 140 | 120 | 30 | 35 | 40 |
| WG67K-80T2500 | 4 tons | 160 | 120 | 35 | 40 | 40 |
| WG67K-80T3200 | 5 tons | 160 | 120 | 35 | 40 | 40 |
| WG67K-80T4000 | 6 tons | 160 | 120 | 35 | 40 | 45 |
| WG67K-100T2500 | 5 tons | 180 | 140 | 40 | 50 | 50 |
| WG67K-100T3200 | 6 tons | 180 | 140 | 40 | 50 | 50 |
| WG67K-100T4000 | 7.8 tons | 180 | 140 | 40 | 50 | 60 |
| WG67K-125T3200 | 7 tons | 190 | 140 | 45 | 50 | 50 |
| WG67K-125T4000 | 8 tons | 190 | 140 | 45 | 50 | 60 |
| WG67K-160T3200 | 8 tons | 210 | 190 | 50 | 60 | 60 |
| WG67K-160T4000 | 9 tons | 210 | 190 | 50 | 60 | 60 |
| WG67K-200T3200 | 11 tons | 240 | 190 | 60 | 70 | 70 |
| WC67E-200T4000 | 13 tons | 240 | 190 | 60 | 70 | 70 |
| WG67K-200T5000 | 15 tons | 240 | 190 | 60 | 70 | 70 |
| WG67K-200T6000 | 17 tons | 240 | 190 | 70 | 80 | 80 |
| WG67K-250T4000 | 14 tons | 280 | 250 | 70 | 70 | 70 |
| WG67K-250T5000 | 16 tons | 280 | 250 | 70 | 70 | 70 |
| WG67K-250T6000 | 19 tons | 280 | 250 | 70 | 70 | 80 |
| WG67K-300T4000 | 15 tons | 300 | 250 | 70 | 80 | 90 |
| WG67K-300T5000 | 17.5 tons | 300 | 250 | 80 | 90 | 90 |
| WG67K-300T6000 | 25 tons | 300 | 250 | 80 | 90 | 90 |
| WG67K-400T4000 | 21 tons | 350 | 250 | 80 | 90 | 90 |
| WG67K-400T6000 | 31 tons | 350 | 250 | 90 | 100 | 100 |
| WG67K-500T4000 | 26 tons | 380 | 300 | 100 | 110 | 110 |
| WG67K-500T6000 | 40 tons | 380 | 300 | 100 | 120 | 120 |
Sample Show & Industry
Packaging
Factory
Our Service
Customer Visit
Off-line Activity
FAQQ: Do you have CE document and other documents for customs clearance?
A: Yes, we have CE, Provide you with a one-stop service.
At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
Q: If we are interested in your machine, how do we choose?
A:Could you tell me your materials:cs or ss and their thickness? And the biggest bending width? Then i will confirm the machine model for you.
