| Model | LX3015FG |
| Working Area | 1500*3000mm |
| Laser Power | 1-30kw |
| Laser Generator | Raycus/MAX/JPT/IPG/Nlight |
| Laser Wave Length | 1064nm |
| Working Table | Sawtooth |
| Maximum Idle Running Speed | 120m/min |
| Maximum acceleration | 1.5G |
| Position Accuracy | ±0.02mm/m |
| Repeat Positional Accuracy | ±0.01mm |
| Control System | Weihong |
| Position Type | red dot |
| Power Consumption | ≤21 KW |
| Working Voltage | 380V /50Hz |
Samples




Customer Visit

Q: Do you have CE document and other documents for customs clearance?
A: Yes, we have original. At first we will show you and after shipment we will give you CE/Packing list/Commercial Invoice/Sales contract for customs clearance.
Q: Payment terms?
A:TT/West Union/Payple/LC/Cash and so on.
Q: I don't know how to use after i receive or i have problem during use, how to do?
A: We can provide team viewer/Whatsapp/Email/Phone/Skype with cam till all of your problems finished.We can also provide door service if you need.
Q: I don't know which one is suitable for me ?
A :Just tell us below information 1) Max work size:choose most suitable model. 2) Materials and cutting thickness:Power of laser generator. 3) Business industries:We sell a lot and give advice on this business line.
